BBR SDX Bar system
The BBR SDX Bar system combines versatility of application with ease of use and offers a solution for every construction and underground engineering challenge. The BBR SDX Bar system is a fully threaded hollow bar system, complete with a selection of accessories, designed to suit the widest variety of ground conditions and working environments. Three levels of corrosion protection are offered – sacrificial corrosion allowance, hot dip galvanization and Galpex, which combines hot dip galvanizing with an epoxy or polyester powder coating for unique durability. BBR SDX bar system can be used for applications as an anchor, soil or rock nail and micropile.
Key features
- Bars can be drilled into loose or collapsing soils without casing
- Continuous thread allows bars to be cut or coupled at any desired point and thus installed in restricted access or limited clearance conditions
- R and T threads are compatible with most drilling machines and also ensure excellent grout bonding characteristics
- Drilling bars can be used to flush and grout the borehole
- Grouting advances simultaneously with drilling and ensures proper grout distribution along the whole bar length
- Mechanical properties of the system allow for application with compression, tension or alternating forces
- Rotary or rotary-percussive drilling consolidates the ground around the tendon and increases system efficiency
BBR SDX Bar system
Self-driling bars for construction and underground applications.
See our Downloads pageCONNÆCT
Read more about the BBR SDX Bar system in this edition.
