BBR VT CONA CMO onion internal post-tensioning anchorage

The European assessed CONA® CMO post-tensioning anchorage is a multi-strand technology with a flat array of onion-bulb strand ends for internally bonded post-tensioned applications particularly in very thin concrete cross-sections such as slabs. Typical applications include car parks, apartment buildings, commercial office space, retail centers and distribution warehouses.

CONA CMO Onion
CONA CMO Spacer

Key features

  • Standard tendon sizes from 2 to 6 strands
  • Optimised for 15.7 mm diameter, 1,860 MPa strand
  • No anti-bursting or splitting reinforcement required at anchorage
  • Innovative clip-lock strand spacer and duct sealing filler enhances productivity on site
  • Very small centre spacings and edge distances at the anchorages
  • Application of full post-tensioning force at very low concrete strengths (fcm,0 = 21/26 MPa)
  • Corrugated round or flat tendon duct utilizing either galvanized steel or plastic material
  • European Technical Assessment and CE marking

CONA CMO assessment

CONA CMO assessment

Download the latest CONA CMO European Technical Assessment

See our Downloads page
